TEL Tokyo Electron 1B80-002789-11 Fiber Interface Board

Brand:TEL Tokyo Electron
Model:1B80-002789-11
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

TEL Tokyo Electron 1B80-002789-11 Fiber Interface Board

Product manual:

1、 Basic Information
Product model: 1B80-002789-11

Product Name: Fiber Optic Interface Board

Manufacturer: Tokyo Electron Limited (TEL, Tokyo Electronics, Japan)

Hardware version number: -11 (indicating the 11th revision of this model)

2、 Main functions

Functional category description
The photoelectric conversion function converts electrical signals into optical signals (transmitting end), or converts optical signals into electrical signals (receiving end)
Long distance transmission uses optical fiber as a medium, with a long transmission distance and no electromagnetic interference
Isolation and protection optical communication naturally has electrical isolation capabilities to ensure the safety of the main control system
Multi channel interface support can support single channel or multi-channel fiber optic transceiver connections for parallel or redundant communication

3、 Typical application scenarios

ACT series lithography auxiliary processing equipment

Used for communication bridging between EFEM (front-end module), main control system, and processing chamber

Tactras/Trias series etching and deposition equipment

Realize remote system connections such as gas path control unit, power module, RF controller, etc

Transfer, Load Port, Robot Control System

Control signals or status data are transmitted back to the main controller via optical fiber over a long distance

4、 Technical features
Onboard SFP or SC/ST type fiber optic interface (depending on version)

Support single-mode or multi-mode fiber optic communication (depending on actual application and wavelength)

The circuit board design meets TEL EMC requirements and has strong anti-static ability

Revision number "-11" indicates that it is an optimized version with better compatibility and signal integrity

Can be installed in TEL control rack BX series or control module, directly connected to the main control board
