TEL Tokyo Electron 1D81-000296-1A Interface PCB Card

Brand:TEL Tokyo Electron
Model:1D81-000296-1A
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

TEL Tokyo Electron 1D81-000296-1A Interface PCB Card

Product manual:

Product Model: 1D81-000296-1A
Name: Interface PCB Card
Manufacturer: Tokyo Electron Ltd. (TEL)
Component Category: Electronic Interface Board/Signal Conversion Module

1、 Product Overview:
The 1D81-000296-1A interface PCB card is an important electronic module used for signal interface and conversion in TEL semiconductor equipment.
This PCB card is mainly responsible for signal transmission, conversion, and isolation between various modules inside the device,
Ensure smooth communication and complete signals between different subsystems.

2、 Main functions:
Function module description
The signal interface supports multiple input and output interfaces for digital and analog signals
Signal conversion to achieve signal conversion and matching of different levels and protocols
Electrical isolation provides optical or electrical isolation, enhancing anti-interference capability
Multi interface design for connection management, facilitating flexible connection and maintenance between modules
Status monitoring supports signal status detection and fault alarm function

3、 Technical parameters (speculation):
Project Description
Interface types include multi pin plugs, terminal blocks, IDC connectors, and various other forms
Signal type TTL/CMOS digital signal, analog voltage, current signal, etc
The power requirement is 5V or 24V DC, depending on the module design
Structural form card type PCB design, convenient for equipment rack installation
Size specifications compatible with TEL equipment standard rack and slot positions

4、 Application scenarios:
Signal interface between controller and sensor within the device

Signal conversion and communication coordination between different subsystems

System signal isolation and anti-interference design

Equipment maintenance and fault diagnosis interface
