TEL Tokyo Electron 2187-100744-11 Power Distribution System

Product manual:

1、 Basic Information
Product model: 2187-100744-11

Product Name: Power Distribution System

Manufacturer: Tokyo Electron Ltd

Product Category: Power Supply/Electronic System Components

Typical application equipment: Semiconductor manufacturing equipment used for TEL, such as etching CVD、 Cleaning or vacuum treatment equipment

2、 Functional positioning
Centralized power distribution module

Convert the main input power (AC or DC) into multiple stable outputs for use by various modules inside the device.

Power protection and isolation

Isolate and short-circuit/overload protect different load circuits to ensure stable and safe power supply for control boards, drivers, sensors, and other modules.

Status monitoring and fault isolation

It can integrate power status indication, alarm, fuse or circuit breaker protection mechanism, support fault location and circuit breaker response.

Power interface integration platform

Integrate multiple voltage levels (such as ± 24V, 5V, 12V, etc.) into a single module to simplify the power supply architecture of the whole machine.

3、 Typical application areas
Power supply for semiconductor equipment control system

Provide multi-channel power support for control motherboards, I/O interface boards, communication modules, vacuum pump drivers, etc.

High reliability distribution requirements

Especially suitable for equipment systems that require extremely high power stability and anti-interference ability in clean room environments.

Modular system distribution architecture

As a standard module in the equipment rack, it is compatible with various TEL power interfaces and wiring harness connection systems.

4、 Technical characteristics (typical)
Supports a wide input voltage range (such as AC 100-240V or DC 24-48V)

Provide multiple independent or isolated outputs (such as ± 24V, 5V, 12V DC, etc.)

Equipped with fuses, EMI filters, surge protection and other components

Supports DIN rail or bolt installation

Compact structure, easy to integrate into TEL control system

Compliant with SEMI and industrial electrical safety regulations

Product details picture:

2187-100744-11
