TEL Tokyo Electron 2981-600395-11 Terminal Module

Brand:TEL Tokyo Electron
Model:2981-600395-11
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

TEL Tokyo Electron 2981-600395-11 Terminal Module

Product manual:

Introduction to TEL Tokyo Electron 2981-600395-11 Terminal Module
Product definition:
2981-600395-11 is a terminal module in Tokyo Electron (TEL) semiconductor equipment,
Mainly used for the connection, distribution, and interface management of multiple electrical circuits within equipment.

Main functions:
Ensure safe connection and distribution of power and signal lines,
Ensure the neatness and reliability of the internal electrical circuits of the equipment, facilitating maintenance and troubleshooting.

Applicable device types:
Widely used in various wafer processing equipment of TEL,
Such as CVD, Etch, Track, Load Port, EFEM and other control cabinets and distribution cabinets.

Connection type:
Supports multi-core cable connection, suitable for DC power lines, control signal lines, ground wires, and communication lines.

Product features:

Multi channel design, reasonable layout, convenient for line management

Having good insulation performance and mechanical fixing structure

With identification strips, it is convenient for quick identification and line checking

Adopting industrial standard guide rail installation for convenient modular layout

Installation location:
Installed inside the control cabinet or distribution cabinet of the equipment, usually fixed on rails or panels,
Used in conjunction with modules such as power boards and controller boards.

Typical application scenarios:

Motor control power supply and signal line distribution

Centralized access of sensor signals

Line management of safety interlock and emergency stop circuit

Collection point for external interface signals
