TEL Tokyo Electron 2985-445336-W1 Interface Block

Brand:TEL Tokyo Electron
Model:2985-445336-W1
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

TEL Tokyo Electron 2985-445336-W1 Interface Block

Product manual:

1、 Product functional positioning
The 2985-445336-W1 interface block is a signal relay and connection component in Tokyo Electron semiconductor manufacturing equipment,
Mainly used for electrical connections and signal distribution between control systems and actuators, sensors, and modules.
It is usually integrated into the rack or control cabinet of the equipment, used for aggregating, distributing, or converting control signals,
To ensure the coordinated operation and maintenance convenience of the equipment system.

2、 Main application areas
1. Equipment signal wiring and interface management platform
Function description:
The interface block connects the main control board (such as controller module, I/O module) with the field devices
The cables between (such as solenoid valves, heating units, vacuum switches, sensors) are centrally connected to serve as relays and busbars.

Typical application scenarios:

Centralized access and unified wiring of control signals;

Standardization of interfaces facilitates equipment debugging and quick replacement;

Form an integrated signal management system with the I/O control module.

2. Signal type conversion or isolation interface
Application Function:

May include functions such as optocouplers, electrical isolation, filtering components, etc., to protect the main control system from signal interference or surge effects;

Realize the conversion of different signal formats (such as TTL → 24V, analog → digital).

3. Auxiliary modules for maintenance and expansion
Design advantages:

Clear wiring terminals facilitate quick wiring, diagnosis, and replacement by on-site engineers;

Support module level expansion, providing flexible interfaces for future process upgrades;

Can be integrated with TEL control module for modular management and upgrading.
