TEL Tokyo Electron 2L08-050053-11 Circuit Board

Brand:TEL Tokyo Electron
Model:2L08-050053-11
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

TEL Tokyo Electron 2L08-050053-11 Circuit Board

Product manual:

1、 Function Overview
This circuit board is a standard control PCB used in TEL semiconductor equipment, mainly serving the following functions:

Realize the reception and distribution of various signals (digital, analog, control signals) in the device

A component used as an interface board or control execution unit between subsystems

May be responsible for tasks such as sensor data acquisition, power control, I/O expansion, relay driving, etc

Sometimes it also undertakes functions such as signal buffering, level conversion, isolation, and protection

2、 Typical application areas
According to the TEL naming convention and numbering range (2L08 usually indicates functions related to sensors/control areas), this circuit board may be used for the following subsystem modules:

1. Sensor signal acquisition system
Collect analog or switch signals such as pressure, temperature, position, liquid level, etc

Docking flow meters, photoelectric sensors, encoders and other devices

2. Gas/liquid flow control system
Control the opening and closing logic of MFC, solenoid valve, and vacuum valve

Monitor the gas-liquid flow status and trigger the interlock protection mechanism

3. Loadlock control area
Assist in controlling door movement, vacuum state detection, gas switching and other operations

Realize the operation status judgment and feedback of precision subsystems

4. Sub board in power or relay control module
Drive small loads, electromagnetic relays, or control signal output channels

Provide onboard protection and filtering functions to ensure the stability of control signals

3、 Technical characteristics (reference)
Industrial grade multi-layer PCB, high temperature resistance and anti-interference

Support multi-channel analog/digital signal input and output

Equipped with standard connectors (such as AMP, Hirose, MIL types)

Equipped with voltage/current regulation, optocoupler isolation or fault indication circuit
