TEL Tokyo Electron 2L81-050035-11 Interface Module

Product manual:

Introduction to TEL Tokyo Electron 2L81-050035-11 Interface Module
Product model: 2L81-050035-11
Product Name: Interface Module
Manufacturer: Tokyo Electron Ltd. (TEL)
Applicable equipment: Used in semiconductor manufacturing equipment for TEL, such as CVD, Etcher, Coater/Developer systems, etc

1、 Core functions
Signal transfer and relay
Used to connect various functional modules within the device, such as control boards, I/O modules, sensors, and actuators, to complete signal transfer, amplification, or matching.

Communication adaptation
Coordinate different communication protocols or signal standards, such as TTL and RS signals, voltage level matching, etc.

Connecting bridges between modules
Connect the main control system and subsystems to ensure modular and collaborative operation of the equipment.

Power or data distribution
Distribute low-voltage power supplies (such as+5V,+12V) or distribute digital signals to multiple sub channels.

2、 Application Fields
Process control system: acts as a control signal bridge in modules such as reaction chamber temperature control, gas control, pump valve control, etc.

I/O relay center: forwards digital/analog signals from on-site devices to the main control unit.

Communication interface extension: used to expand the data communication capabilities of TEL devices, supporting multi-channel and multi protocol connections.

System level signal integration: Centralize and unify multiple sub modules into the system backbone structure for easy debugging and maintenance.

3、 Product features (based on universal design of TEL interface module)
High signal integrity and strong anti-interference ability

Modular standard size, compatible with TEL dedicated backplane or rack systems

Multi pin interface or ribbon cable connection, supporting quick plugging and unplugging

Industrial grade design, suitable for clean rooms and high reliability environments

Support hot swappable maintenance, easy to replace

Product details picture:

2L81-050035-11
