TEL Tokyo Electron 2L81-050095-11 Control Pulse Card

Product manual:

TEL Tokyo Electron 2L81-050095-11 Control Pulse Card
It is a high-precision control module used in Tokyo Electronics (TEL) semiconductor manufacturing equipment,
Responsible for generating and managing pulse signals required for critical equipment components,
Commonly used for driving, timing, or synchronizing related execution components, it is one of the core components for achieving efficient automation control in equipment.

1、 Basic Product Information
Project Content
Product Name: Control Pulse Board
Product model 2L81-050095-11
Manufacturer Tokyo Electron Ltd
Installation method: Plug in module, installed in the control system rack or motherboard slot

2、 Core functions
Pulse signal output

Used to generate programmable pulse signals to drive components such as stepper motors, servo drivers, actuators, etc;

Control the core actions of equipment such as start stop, position movement, and switching rhythm.

Precise timing and synchronous control

Implement timing control of actions between multiple subsystems or components in the process flow;

Support collaboration with the main control board to complete complex linkage logic control.

Signal isolation and protection

Built in electrical isolation structure to prevent external high-frequency interference or abnormal voltage from entering the main control system;

It has basic overload and overvoltage protection functions.

3、 Typical application scenarios
Coater/Developer

Control the precise movement rhythm of the rotating platform, coating arm, or developing mechanism;

Manage the switching pulses of pneumatic or electric valves.

Wafer handling system

Control the stepping action of the robotic arm or lifting platform to achieve precise transmission and positioning;

Coordinate the synchronous operation between different process stations.

Process coordination and control

Pulse output signals used in systems such as plasma etching, vacuum treatment, or heat treatment;

Provide synchronous trigger signals to achieve precise control of process rhythm.

Product details picture:
