TEL Tokyo Electron 3108-060021-11 Analysis Board

Brand:TEL Tokyo Electron
Model:3108-060021-11
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

TEL Tokyo Electron 3108-060021-11 Analysis Board

Product manual:

Product Name: 3108-060021-11 Analysis Board
Manufacturer: Tokyo Electron Ltd. (TEL)
Product type: Analysis Board/Diagnostic Board

1、 Product Overview
TEL 3108-060021-11 Analysis Board
It is a specialized electronic module applied in semiconductor manufacturing equipment, mainly used for monitoring, diagnosing, and analyzing equipment operation data.
It usually exists as an important component for system monitoring and auxiliary control, helping to improve the stability and maintainability of equipment.

2、 Main functions
Signal analysis and acquisition

Real time collection of operational data from sensors, actuators, or main control units.

Process analog/digital signals to determine parameters such as signal amplitude, level, waveform, etc.

Status monitoring and fault detection

Check whether the key control signals are normal and determine whether the components are in the preset state.

Provide abnormal alarm output for quick problem localization.

Data feedback interface

Feedback the analysis results to the main control unit or upper system for software logic use.

May have debugging or maintenance communication ports (such as UART/RS232).

3、 Applicable fields
This analysis board is generally used in the following Tokyo Electron system modules:

Etcher equipment

Thin film deposition equipment (CVD/PVD)

Coater/Developer

Cleaning or testing internal subsystem modules in the system

4、 Technical characteristics (typical features, depending on the version)
Project Description
Power input 24V DC (or powered by backplane)
Signal type: digital IO, analog input, pulse counting, etc
Onboard chips may include AD/DA converters, MCUs, etc
Interface pins, backplane connectors, debugging serial ports, etc
Installation methods: slot type, screw fixed type
