TEL Tokyo Electron 3281-000088-12 Motor Distribution Board

Product manual:

The TEL Tokyo Electron 3281-000088-12 Motor Distribution Board is a critical control module in semiconductor manufacturing equipment, used for centralized distribution and management of power and control signals for multiple motors, ensuring efficient and safe operation of the motor system.

1、 Basic Product Information
Project Content
Product model 3281-000088-12
Product Name: Motor Distribution Board
Manufacturer Tokyo Electron Ltd. (TEL)
Module type: Motor power supply and control signal distribution module

2、 Main functions
Detailed description of functional categories
Motor power distribution distributes the main power to multiple motor drive units to ensure stable power supply to each drive module.
Control signal management centrally manages motor start, stop, speed adjustment and other control signals from the controller.
The protection function integrates overcurrent and short-circuit protection to prevent damage to the motor and control board.
State feedback monitoring of motor operation status and feedback to the main control system to achieve real-time monitoring.

3、 Application Fields
Application System Function Description
The wafer handling system manages the power supply and control signals of multiple motors such as conveyor belts and motor drive arms.
The automated robotic arm coordinates the synchronous starting and control of the motors for each axis of the robotic arm.
Auxiliary equipment controls auxiliary motors such as cooling fans and pumps.

Product details picture:

3281-000088-12
