TEL Tokyo Electron 3381-001039-11 Lighting Control Board

Product manual:

Introduction to TEL Tokyo Electron 3381-0001039-11 Lighting Control Board
1、 Basic Information
Product model: 3381-001039-11

Product Name: Lighting Control Board

Alias: PST-OPT2

Manufacturer: Tokyo Electron Ltd. (TEL)

Typical application equipment: TEL semiconductor equipment (such as coating and developing machines, etching equipment, etc.)

2、 Main functions
Lighting power control
Control the lighting system inside the equipment or process chamber, including power supply, start stop, brightness adjustment, etc.

Security and visibility support
Ensure sufficient lighting in the equipment operation area or observation window to improve operational safety.

System Communication and Response
Can be connected to the main control system to achieve automatic light on/off or alarm prompt functions according to the workflow.

3、 Application Fields
Semiconductor manufacturing equipment (Etcher, Coater/Developer, cleaning equipment, etc.)

Visual lighting system for process monitoring area

Auxiliary control subsystem of cleanroom equipment module

Spare parts for equipment maintenance and replacement

4、 Precautions for use
Confirm interface matching and device model consistency before installation to avoid electrical incompatibility.

Installation and debugging must be carried out in accordance with TEL's original technical specifications to avoid lighting abnormalities or system false alarms.

Regularly check the lighting output status and response logic to ensure continuous functionality.

If frequent damage occurs, it is necessary to check the status of the relevant power module or signal line.

Product details picture:

3381-001039-11
