TEL Tokyo Electron 381-640804-9 Display Panel

Brand:TEL Tokyo Electron
Model:381-640804-9
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

TEL Tokyo Electron 381-640804-9 Display Panel

Product manual:

Product model: TEL Tokyo Electron 381-640804-9
type: Display Board
Functional positioning: A key module in semiconductor equipment used for graphical information output, human-computer interface interaction, and operational status display

1、 Product Function Overview:
381-640804-9 display board
It is a specialized information visualization module designed by Tokyo Electron (TEL) for its high-end semiconductor manufacturing equipment.
This display panel can be connected to LCD or LED screens for real-time display of device operating status, process parameters, alarm information, and user interface.
Its design meets the requirements of high stability and reliability of clean room equipment, and supports multiple communication protocols and integration with the main control system.

2、 Main application areas:
Visualization display of process parameters

Display key process data such as temperature, pressure, gas flow rate, operating steps, and vacuum status.

Equipment status and alarm information prompt

Real time output of operating status (such as idle, process, error), supporting multi-level alarm display and code prompt functions.

Human Machine Interaction Support (HMI)

Cooperate with the touch control screen or button panel to achieve interactive functions such as parameter setting, menu browsing, start/stop control, etc.

System diagnosis and maintenance prompts

Display system self-test results, log information, and maintenance suggestions to improve equipment troubleshooting efficiency.

Communication and Control Interface

Communicate with the main control system through RS-232, CAN, Ethernet, or dedicated protocols as a status feedback and command display terminal.
