TEL Tokyo Electron 3880-200047-24 Control Pulse Card

Product manual:

TEL Tokyo Electron 3880-200047-24 Control Pulse Board
It is a high-precision signal output module specifically designed for control systems, mainly used in TEL semiconductor equipment,
Used to control the generation, transmission, and distribution of pulse signals, it is one of the important components for equipment to perform control actions,
Commonly used in key control logic such as timed triggering, drive synchronization, and signal shaping.

1、 Basic Information
Product Name: Control Pulse Board

Product model: 3880-200047-24

Manufacturer: Tokyo Electron Ltd. (TEL)

Function type: Pulse signal control and output module

Installation location: inside the main control rack or signal control board frame

2、 Main functions
Pulse signal output control

Generate customized pulse signals to trigger external devices such as drivers, valves, electromagnets, etc.

Support high-frequency and precise timing control requirements.

Signal allocation and shaping

Convert the control commands of the main control system into standard pulse form and allocate them to multiple execution units.

Shape and filter the input signal to enhance its anti-interference ability.

Equipment action synchronization

Ensure that multiple control units operate according to the set timing to achieve synchronous control logic within the device.

Can be used to trigger process nodes such as step actions and process transitions.

Process control interlock interface

Support the interlocking logic of the process, such as outputting precise pulse signals to start the next step after reaching a certain condition.

Product details picture:
