TEL Tokyo Electron 3D80-001480-V1 Power Unit Component

Product manual:

Tokyo Electron 3D80-001480-V1 Power Supply Unit Assembly
It is an industrial grade power module component used in semiconductor equipment,
Specially designed to provide stable and reliable multi-channel DC power output for Tokyo Electron (TEL) high-precision equipment control systems,
Ensure long-term stable operation of various functional modules (such as processors, I/O control boards, interface modules, sensor systems, etc.).

1、 Basic Information
Product model: 3D80-001480-V1

Product Name: Power Supply Unit Assembly

Manufacturer: Tokyo Electron Ltd. (TEL)

Component type: Modular power system/Industrial power distribution component

Typical equipment applications: TEL Etch, CVD, Coater/Developer, EFEM and other main control racks

2、 Core functions
Multi channel DC power output

Provide different voltage levels (such as+24V,+12V,+5V, ± 15V DC) to multiple subsystems;

Meet the power requirements of control systems, I/O modules, CPU boards, display modules, etc.

Input voltage stabilization and filtering

Receive AC or DC main input power and process it through internal rectification and voltage regulation circuits;

Built in filtering, surge suppression, overvoltage protection and other functions enhance system stability.

Modular output interface

Connect the power output to each control board using backplane or aviation plugs;

Support redundant output and independent channel management to improve system reliability and maintenance efficiency.

System status monitoring

Capable of output status monitoring and fault diagnosis (such as overload, overheating, undervoltage);

The power status signal can be fed back to the main control system (such as 3D81- or E244 series controllers).
