TEL Tokyo Electron 3D81-000017-V3 power module

Brand:TEL Tokyo Electron
Model:3D81-000017-V3
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

TEL Tokyo Electron 3D81-000017-V3 power module

Product manual:

Introduction to TEL Tokyo Electron 3D81-000017-V3 Power Module
Product definition:
3D81-000017-V3 is a dedicated power module for Tokyo Electron semiconductor equipment,
Used to provide stable DC power supply for subsystems such as control systems, driver boards, sensors, etc.

Main functions:
Convert AC input power (such as AC 100~240V) into multiple stable DC outputs
(such as+24V,+12V,+5V, etc.), providing power to critical circuits inside the equipment.

Typical application devices:
Widely used in TEL wafer etching systems (Etch), CVD systems, ALD systems
Cleaning systems and other high-end semiconductor process equipment are an indispensable part of the control system.

Support output range:
The output voltage may contain a single or multiple sets of DC voltages, and the current capacity supports the simultaneous operation of multiple modules,
And it has low ripple output characteristics, meeting the requirements of precision control.

Product features:

High reliability, composed of industrial grade components

Multiple protections: overvoltage, overcurrent, short circuit, and over temperature protection

Modular design, easy to install and replace

Strong stability, suitable for precision electronic environments

Installation location:
Usually located in the control cabinet or main power compartment of the equipment, close to the interface board or controller, fixed with rails or screws.

Application scenarios:

Control the power supply of the motherboard

I/O interface, sensor power supply

Power supply for equipment such as solenoid valves and MFCs (mass flow meters)

Provide energy support for subsystem modules such as fans, motor drivers, etc
