TEL Tokyo Electron 3D81-000018 Motor Distribution Board

Brand:TEL Tokyo Electron
Model:3D81-000018
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

TEL Tokyo Electron 3D81-000018 Motor Distribution Board

Product manual:

Introduction to TEL Tokyo Electron 3D81-000018 Motor Distribution Board
Product definition:
3D81-000018 is a motor distribution board in Tokyo Electron (TEL) equipment,
Mainly used for centralized management of power and control signal distribution for multiple motors, it is one of the core components in motion control systems.

Main functions:
The control signals of future autonomous controllers (such as PLCs or motion control cards)
The power signal is distributed to multiple motor channels to achieve coordinated driving and zone management of multiple motors.

Applicable device types:
Wafer processing equipment suitable for TEL, such as CVD (chemical vapor deposition), Etch (dry etching), Coat/Developer (coating development)
Load Port, EFEM automation module, etc.

Supported motor types:

stepping motor

servo motor

DC/brushless motor
The board may integrate motor drive interfaces or work in conjunction with external drivers.

Product features:

Multi channel output, supporting simultaneous connection of multiple motors

Equipped with overcurrent protection, fuses, control relays and other components

Can receive input signals such as position feedback and limit switches

Clear wiring, equipped with status indicator lights for easy debugging and maintenance

Installation location:
Generally located in the control module area and motion control subsystem inside the device,
Close to the actuator or motor body to shorten the cable path and reduce interference.

Typical application scenarios:

Multi axis control of wafer handling robotic arm

Lifting platform or alignment mechanism

Coordinated control of motors for rotating, loading/unloading devices

Motor management of mask moving and clamping mechanism

Product details picture:
