TEL Tokyo Electron 3D81-000030-11 Electronic Connection Board

Brand:TEL Tokyo Electron
Model:3D81-000030-11
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

TEL Tokyo Electron 3D81-000030-11 Electronic Connection Board

Product manual:

Introduction to TEL Tokyo Electron 3D81-000030-11 Electronic Connection Board
Product definition:
3D81-000030-11 is an electronic connection board in Tokyo Electron (TEL) equipment,
The main function is to serve as a signal and power connection hub between multiple circuit modules,
Realize efficient communication and power transmission between internal modules of the device.

Main functions:

Centralize the connection of signal lines and power lines for different circuit boards and submodules

Realize data transmission and electrical isolation between modules

Provide stable interface connections to ensure the overall reliability of the system operation

Applicable device types:
Widely used in various semiconductor manufacturing equipment of TEL,
Including CVD, Etch, ALD, cleaning systems, automatic handling equipment, etc.

Connection interface type:

Multi pin connector

Pin/Mother connector

Terminal block connection, etc., supporting high-speed signal and power line connection

Product features:

High density interface design, saving equipment space

Excellent electrical performance, low impedance and low-noise transmission

Sturdy structure, anti vibration design suitable for clean room environment

Modular design for easy and quick replacement and maintenance

Installation location:
Generally installed inside the equipment control cabinet or chassis as a bridge between multiple functional modules.

Typical application scenarios:

Controller and sensor interface connection
