TEL Tokyo Electron 3D81-000031-V3 Interface Board

Product manual:

Product model: 3D81-000031-V3
Name: Interface Board
Manufacturer: Tokyo Electron Ltd. (TEL)
Component Category: Signal Interface and Communication Module

1、 Product Overview:
The 3D81-000031-V3 interface board is a key communication and signal conversion module in TEL semiconductor equipment.
This interface board is responsible for signal transmission, conversion, and protocol adaptation between various subsystems within the device,
Ensure efficient and stable data exchange and control signal transmission between device modules.

2、 Main functions:
Function module description
Multi signal interface supports input and output interfaces for both digital and analog signals
Communication protocol supports commonly used industrial communication protocols such as RS-232, RS-485, CAN, etc
Signal isolation adopts electrical isolation technology to improve anti-interference performance
Real time monitoring of interface status through status monitoring, supporting fault alarms
Connection management facilitates the connection and maintenance between modules, and supports hot swappable functionality (if applicable)

3、 Technical parameters (based on similar interface board specifications):
Parameter Description
Interface types include multi pin connectors, terminal blocks, D-sub, and other standard interfaces
Signal type TTL/CMOS digital signal, analog signal
The power requirement is 5V or 24V DC, depending on the specific design
Communication speed supports communication speeds ranging from hundreds of kbps to Mbps
Structural form card insertion or rack mounted installation design

4、 Application scenarios:
Signal and data communication between device modules

Interface bridging between sensors and controllers

System diagnosis and signal status monitoring

Expansion of Communication Interface for Industrial Automation Equipment

Product details picture:
