TEL Tokyo Electron 3M80-001321-25 PCB board

Brand:TEL Tokyo Electron
Model:3M80-001321-25
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

TEL Tokyo Electron 3M80-001321-25 PCB board

Product manual:

TEL Tokyo Electron 3M80-001321-25 PCB board
It is a customized printed circuit board used in TEL semiconductor equipment,
Mainly used for electronic signal processing, module interconnection, control signal transmission, or subsystem drive control functions,
Commonly found in core equipment such as Etch, CVD, Wet Bench, and EFEM in TEL.

1、 Basic Information
Product model: 3M80-001321-25

Product Name: Printed Circuit Board

Manufacturer: Tokyo Electron Ltd. (TEL)

Installation location: main control rack, submodule control box, interface compartment, etc

Usage category: Control class/Signal processing class/Interface driver class Printed circuit board

2、 Function Overview
Due to the fact that this model is a customized board (not a universal standard part), its functions need to be analyzed specifically based on the installation location and supporting system. Generally, it has one of the following types of functions:

1. Signal processing and distribution
Responsible for receiving signals from the main control module, interfacing with external I/O, actuators, sensors, etc;

Provide signal conditioning, level conversion, or isolation protection functions.

2. Module connection and bridging
Used for electrical connection between the motherboard and daughter cards;

May serve as a backplate, signal adapter board, or universal bridging interface board.

3. Auxiliary power distribution
Distribute the main power supply voltage (such as+24V,+12V,+5V) to multiple subsystems;

Provide overcurrent protection, voltage regulation, or filtering processing functions.

4. Perform control functions
Control specific component actions, such as fans, valves, heating units, motor control, etc;

Contains relays, transistors, driver chips, or interface chips.
