TEL Tokyo Electron 3S86-000280-14 Relay Module

Product manual:

Introduction to TEL Tokyo Electron 3S86-000280-14 Relay Module
1、 Basic Information
Product model: 3S86-000280-14

Name: Relay Board

Manufacturer: Tokyo Electron Ltd. (TEL)

Typical structural code: CB6S8S-4-M1

Application type: Device execution circuit control

2、 Function and Features
Circuit switching control
Control the on/off of external device power circuits such as pumps, valves, fans, or heaters through relays.

Electrical isolation
Using relays to provide isolation between the control system and high-voltage equipment, improving the overall safety and stability of the system.

Modular integration
Connect to the control motherboard or backplane in the form of a plug-in board for easy system expansion and later maintenance and replacement.

3、 Application Fields
Semiconductor equipment: widely used in TEL etching machines, CVD equipment, cleaning equipment and other models.

Industrial automation control system: undertakes the function of executing multiple outputs in situations where multi-point output control is required.

Signal control and load drive: connected to end load devices such as relay cabinets, solenoid valves, and electric equipment.

4、 Precautions for use
Confirm interface definition: Ensure that each pin or signal channel matches the control system when connected to the system.

Installation standard operation: The plugging and unplugging operation should be carried out when the device is powered off to prevent misoperation or damage.

Regular inspection and maintenance: Check for carbonization or looseness of the contacts, and replace or clean them if necessary.

Load capacity matching: Do not exceed the maximum allowable load voltage and current of the module, otherwise it may burn out.

Product details picture:
