TEL Tokyo Electron 710-806050-01 Single Board Computer

Product manual:

1、 Basic Information
Product model: 710-806050-01

Product Name: Single Board Computer (SBC)

Manufacturer: Tokyo Electron Ltd

Functional positioning: As the main control unit or embedded control platform of the device, it runs control software, executes process flow, and coordinates subsystem communication.

2、 Main functions

Data processing and real-time response

Process data from sensors, interface modules, and operation panels and make real-time control logic responses.

Communication and Network Management

Provide Ethernet, serial port USB、 Communication interfaces such as fieldbus support connection with upper computer (such as FAB management system) and local devices (such as pumps, valves, sensors).

Equipment status monitoring and logging

Real time recording of equipment operating status, alarm information, maintenance logs, etc., for process traceability or fault diagnosis.

3、 Application Fields
Semiconductor manufacturing equipment main control platform

Applied to etching equipment (Etch), chemical vapor deposition equipment (CVD), photolithography process assistance systems, wafer processing and transport systems, etc. of Tokyo Electron.

Embedded subsystem control unit

As the core control platform in independent process units such as gas path control units, temperature control subsystems, and power control systems.

Industrial Communication Management Center

Centralized management of I/O modules PLC、 Data exchange between display modules and remote operation terminals.

4、 Technical features (typical configuration)
The specific configuration may vary slightly with the revised version, and this is a common industrial grade SBC feature:

Industrial grade CPUs (such as Intel Atom/Pentium/ARM Cortex series)

Supports SDRAM/DDR memory slots, typically ranging in capacity from 512MB to 4GB

Provide SATA or CF/SSD storage interfaces

Multiple communication interfaces: Ethernet, RS-232/422, USB, GPIO

Supports graphic display output: VGA, LVDS, or DVI (for local interface display)

High stability, low-power design, suitable for clean rooms and vacuum environments

Support remote updates, remote diagnostics, and self recovery functions

Product details picture:

710-806050-01
