TEL Tokyo Electron 909-031-PLC4A power module

Brand:TEL Tokyo Electron
Model:909-031-PLC4A
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

TEL Tokyo Electron 909-031-PLC4A power module

Product manual:

Product Name: 909-031-PLC4A Power Module
Manufacturer: Tokyo Electron Ltd
Product type: Power Supply Module

1、 Product Overview
909-031-PLC4A is a dedicated power module used in Tokyo Electron semiconductor equipment, mainly providing stable DC power supply for control boards, interface modules, sensors, or execution components in the equipment. It is typically deployed in control racks, power distribution cabinets, or modular frameworks and is one of the key foundational hardware components.

2、 Main functions
DC stabilized power supply

Convert AC input or high voltage DC into stable low voltage DC output required by the equipment, such as 5V/12V/24V DC.

Overload and short circuit protection

Built in protection circuit effectively prevents faults caused by voltage overshoot, short circuit, or current overload.

Support multi-point power supply

It can simultaneously supply power to multiple sub modules or subsystems, providing multiple output channels.

Equipment operation indication

Equipped with status indicator lights (such as Power OK, Fault, etc.) for easy monitoring of operational status.

3、 Typical application devices
This power module is suitable for power systems in the following TEL semiconductor manufacturing equipment:

Etcher series etching equipment

CVD/PVD vacuum film equipment

Coater/Developer

Cleaning and heat treatment equipment

4、 Technical parameters (typical range, specific depending on version)
Typical numerical values/descriptions for parameter categories
Input voltage 100-240V AC or 48V DC (depending on configuration)
Output voltage multi-channel, such as 5V DC/12V DC/24V DC
Maximum power 50W-200W (varies depending on the actual model)
Interface type: Terminal block/plug connector
Cooling method: natural air cooling or built-in small fan
Installation method: rack mounted/rail mounted/panel screw fixed
