TEL Tokyo Electron CPC-T0033A-12 Input/Output Module

Product manual:

1、 Basic Information
Product model: CPC-T0033A-12

Product Name: Input/Output Module

Manufacturer: Tokyo Electron Limited (TEL)

Product Category: I/O Interface Board/Control Expansion Module

Revision version: -12 represents the 12th edition of this model, adapted to specific device configurations or software versions

2、 Main functions
Functional category description
Digital input receives switch signals, such as limit switches, sensors, button status, etc
Digital output controls the on/off status of actuators such as solenoid valves, relays, indicator lights, etc
Partial versions of the analog interface (depending on configuration) may support analog input/output for collecting signals such as voltage, current, temperature, etc
Signal isolation and buffering provide electrical isolation and signal stability, avoiding interference between devices
The system communication interface is connected to the main control unit to achieve real-time data transmission and control command response

3、 Application scenarios
CPC-T0033A-12 is widely used in various semiconductor devices of TEL to achieve unified management and execution control of device signals. It is commonly used in:

Photolithography pre-processing and post-processing equipment (such as ACT series):
Control the developing arm, sensor feedback, liquid control valve, lifting mechanism, etc

CVD/Etch system:
Receive signals such as pressure, vacuum, gas flow, etc., and control switch components and auxiliary mechanisms

Transfer Modules:
Manage key action signals such as handling robotic arm, turntable limit, door lock control, etc

4、 Module features
Industrial grade stability design, suitable for clean rooms and high load operating environments

Multiple channels, high integration, flexible allocation of input/output resources

The hardware version "-12" indicates that it has undergone feature enhancement or compatibility optimization

Highly compatible with TEL's original control system to ensure long-term stable operation

Product details picture:

CPC-T0033A-12
