TEL Tokyo Electron CX08-050026-11 Printed Circuit Board

Product manual:

Product Name: CX08-050026-11 Printed Circuit Board (PCB)
Manufacturer: Tokyo Electron Ltd
Product type: Printed Circuit Board

1、 Product Overview
CX08-050026-11 is a specialized printed circuit board used in Tokyo Electron semiconductor equipment,
Mainly responsible for signal transmission, control logic, or interface connection functions.
This PCB may be integrated into the control system, I/O module, or driver unit of the device.

2、 Main functions
As a carrier of electronic components, it realizes circuit connection and signal transmission

Supports digital/analog signal input and output

Possible integration of partial control logic or interface driver circuits

As an electrical connection bridge between modules, ensure stable operation of equipment

3、 Applicable equipment
This type of PCB is commonly found in the following Tokyo Electron equipment systems:

Etcher equipment

Thin film deposition equipment (CVD, PVD)

Coater/Developer

Mechanical action and transmission control module

4、 Technical characteristics (general reference)
Parameter Description
Multi layer board (usually 4 or more layers)
Material FR4 or higher frequency dedicated material
Interface type: Pin, terminal, ribbon connector, etc
The rated voltage is usually 5V, 12V, or 24V DC
Installation method: screw fixation or slot installation
Adapt to clean room and industrial environments in the working environment

Product details picture:
