TEL Tokyo Electron CX81-050049-1 Controller Module

Brand:TEL Tokyo Electron
Model:CX81-050049-1
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

TEL Tokyo Electron CX81-050049-1 Controller Module

Product manual:

Product Model: CX81-050049-1
Name: Controller Module
Manufacturer: Tokyo Electron Ltd. (TEL)
Component Category: Control Unit/Processing Module

1、 Product Overview:
The CX81-050049-1 controller module is the core control unit in TEL semiconductor equipment,
Responsible for logical operations, data processing, and system coordination of equipment.
This module integrates high-performance processors and rich interfaces to achieve real-time monitoring and instruction issuance of various subsystems of the device.

2、 Main functions:
Function module description
Logic Control Execution Device Control Logic and Process Management
Data processing, collection, and processing of sensor and submodule data
Communication interface supports communication with other control modules and upper computer
Real time monitoring of equipment operation status and alarm management through status monitoring
System coordination and coordination of multiple modules working together to ensure process stability

3、 Technical parameters (speculation):
Parameter Description
Processor type: Embedded microcontroller or CPU, model depends on the device
Storage capacity includes built-in flash memory and RAM for program storage and data caching
The communication interface supports multiple protocols such as RS-232, RS-485, Ethernet, etc
The power requirement is 5V or 24V DC, depending on the module design
Dimensions: Plug in card design, compatible with TEL equipment rack

4、 Application scenarios:
Central control unit for semiconductor manufacturing equipment

The core processing module of equipment automation process

Data Collection and Processing Platform

Equipment status monitoring and alarm management system
