TEL Tokyo Electron DS1181-000957-11 Interface Panel

Brand:TEL Tokyo Electron
Model:DS1181-000957-11
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

TEL Tokyo Electron DS1181-000957-11 Interface Panel

Product manual:

Introduction to TEL Tokyo Electron DS1181-000957-11 Interface Panel
1、 Basic Information
Model: DS1181-000957-11

Nickname: MC-31027

Type: PHOTO MOS interface board

Manufacturer: Tokyo Electron Ltd. (TEL)

Application equipment: mainly used for TEL Alpha 8se/a8s series furnaces

2、 Function Description
Signal Control
Responsible for controlling the signal transmission of valves and mass flow controllers (MFCs) in the equipment, ensuring accurate regulation of fluids and gases.

Interface conversion
As an interface panel for electronic control signals, it enables signal connection and conversion between the upper control system and actuators.

system integration
The automatic control system integrated into semiconductor manufacturing equipment supports precise process control of the equipment.

3、 Application scenarios
Valves and gas flow control systems in semiconductor manufacturing equipment

Equipment maintenance and spare parts replacement

Process automation and stability improvement

4、 Precautions for use
Compatibility confirmation: Before installation, confirm that the interface panel is compatible with the device model to avoid mismatches that may cause malfunctions.

Installation specifications: Follow the installation instructions provided by the equipment manufacturer to ensure correct wiring and secure fixation.

Functional testing: After the first use or replacement, it is recommended to conduct functional testing to ensure normal operation.

Regular maintenance: Regularly check the condition of the interface board to prevent dust and poor contact from affecting equipment performance.
