TEL Tokyo Electron E249-000003-11 Screen Display Module

Brand:TEL Tokyo Electron
Model:E249-000003-11
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

TEL Tokyo Electron E249-000003-11 Screen Display Module

Product manual:

Product Name: E249-000003-11 Screen Display Module
Manufacturer: Tokyo Electron Ltd
Product Type: HMI Display Module

1、 Product Overview
E249-000003-11 is a human-machine interaction display module used for on-site status monitoring and operation interface display in Tokyo Electron semiconductor equipment.
This module provides a visual interface for operators to display equipment operating status, alarm information, and process parameters,
And performing basic control operations is the key interaction window between the control system and users.

2、 Core functions
Real time data visualization display

Display current process parameters and equipment status (such as temperature, pressure, valve opening and closing, motor operation, etc.).

User interface

Provide graphical interfaces such as menus, buttons, and selection options for operators to set device parameters, start, pause, reset, and perform other operations.

Alarm and prompt information

Real time pop-up of abnormal information and alarm codes to assist maintenance personnel in quickly locating problems.

System menu navigation

Embedded system control menu, supporting function grading, password access control, etc.

communication function

Communicate with the main control CPU, PLC or controller module, receive or send control instructions and data display.

3、 Typical application devices
This module is widely used in the following TEL devices or subsystems:

Etcher Console

Process Display Interface of CVD/PVD Thin Film Deposition System

Coater/Developer operation terminal

Control stations for vacuum chambers, gas panels, and transmission systems
