TEL Tokyo Electron EC80-0000180-15 Port Hub

Product manual:

TEL Tokyo Electron EC80-0000180-15 Port Hub
It is a key communication device used in Tokyo Electron semiconductor equipment to achieve centralized data and signals between multiple devices and modules.
It usually serves as a communication hub, supporting the connection, management, and allocation of multiple communication lines,
Ensure the orderly and efficient transmission of data flow inside and outside the equipment.

The following is a detailed introduction to the application areas and functions of the port hub (without graphics):

1、 Basic Information
Product model: EC80-0000180-15

Product Name: Port Hub

Manufacturer: Tokyo Electron Ltd. (TEL)

Equipment type: Communication centralized management module

2、 Main functions
Multi port data aggregation and distribution

Support signal collection and distribution for multiple input/output ports;

Realize data flow between multiple control modules, sensors, and peripheral systems within the device.

Communication Protocol Management

Compatible with internal standard communication protocols of TEL devices;

Supports various interface forms such as industrial Ethernet, serial communication, TTL, etc.

Signal conversion and isolation

Realize interconnection and intercommunication of different signal types;

Provide electrical isolation function to ensure stable signal transmission and prevent interference.

Status monitoring and fault diagnosis

Built in status indicator lights and diagnostic interfaces for real-time monitoring and troubleshooting;

Support link state detection and automatic recovery function.

3、 Typical application areas
Communication Management of Semiconductor Manufacturing Equipment

As a communication hub between the control system and process modules;

Connect multiple I/O modules, sensor modules, and main control units.

Factory automation network integration

Support data interfaces with upper level systems such as MES and SCADA;

Realize collaborative control and information sharing among production line equipment.

Equipment expansion and maintenance

Facilitate the integration and access of newly added modules;

Simplify the maintenance and upgrade process.

Product details picture:

EC80-000180-15
