TEL Tokyo Electron ES1D80-001291-13 Power Supply Unit

Product manual:

TEL Tokyo Electron ES1D80-001291-13 Power Supply Unit
(Corresponding OEM original model: Sanken MLT-DCB0X5/DCBOX5)

major function
This is a multi-channel DC output power module that provides stable power support for various electronic control systems inside TEL semiconductor equipment,
Supports multiple voltage rail outputs and is widely used in high-precision control and driving circuits.

Typical technical parameters (reference values)
Input voltage: 90-110 VAC, approximately 6.5 A

Output voltage channel:

+5V / 10A

+15V / 1.7A

–15V / 2A

+24V / 4.1A

+12V / 3A
These outputs are used to provide different voltage levels required for control boards, signal boards, execution units, etc.

Product application areas
1. Power supply system for plasma etching equipment
Widely used in TEL's plasma etching equipment (such as the Unity II U2-855DD series),
Provide multiple power sources for key components such as control systems, RF modules, vacuum interfaces, and cavity control.

2. Power supply for equipment control board and VME bus system
Control the motherboard, input/output module (I/O), interface board in the device
Multiple subsystems such as logic processing units provide their respective required voltages to meet the simultaneous power supply needs of complex circuits.

3. Sensor and actuator module drivers
Used for various precision sensors, valve controllers, servo units
Electromagnetic drivers and other modules are powered to ensure real-time and accurate process control.

4. Process control system and safety monitoring power supply
Provide stable power supply for modules related to temperature, air pressure, vacuum, and flow control,
Support real-time monitoring and control of device operating status.

5. Strong compatibility between equipment maintenance and module replacement
Its modular and multi voltage output design facilitates equipment replacement in case of faults
Quick integration during upgrade and expansion, reducing system downtime and improving maintenance efficiency.

Product details picture:
