TEL Tokyo Electron F18-623007-2 Ultrasonic Module

Product manual:

1、 Basic Information
Product model: F18-623007-2

Product Name: Ultrasonic Module

Manufacturer: Tokyo Electron Ltd

Module type: Ultrasonic sensing and measurement module

Application areas: Used for liquid level detection, distance measurement, level monitoring, etc. in semiconductor manufacturing equipment.

2、 Functional positioning
Ultrasonic signal transmission and reception

Send ultrasonic signals and receive their reflected waves for measuring the position of target objects or the liquid level height of liquids.

Signal Processing

Convert the received ultrasonic signal into an electrical signal, filter and amplify it, and output digital or analog measurement results.

Distance and liquid level measurement

By measuring the propagation time of ultrasonic waves to calculate distance, precise liquid level or distance monitoring can be achieved.

Safety and Protection

Capable of anti-interference and adapting to special working environments such as clean rooms.

3、 Application Fields
Liquid tank level detection

Used for real-time monitoring of liquid levels in chemical tanks, cleaning tanks, waste liquid tanks, etc.

Distance measurement within the device

Monitor mechanical components, conveyor belts, material positions, etc.

Anti collision and object detection

Object proximity detection within equipment or automation systems.

4、 Technical characteristics (typical)
The frequency range is suitable for mid to high frequency ultrasound (usually in the tens to hundreds of kilohertz range)

High sensitivity ultrasonic transducer

Integrated signal processing circuit, supporting output of analog voltage or digital signal

Equipped with temperature compensation and noise suppression functions

Industrial grade design, suitable for use in clean room environments

Interface compatible with TEL device control system standards

Product details picture:

F18-623007-2
