TEWS TPMC871-10 interface module

Model: TPMC871-10
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

TEWS TPMC871-10 interface module

Product manual:

TEWS TPMC871-10 Interface Module

Overview
TPMC871-10 is a PMC (PCI Mezzanine Card) interface module produced by TEWS Technologies, used to expand the bus connection capability of PCMCIA or CardBus devices in embedded systems.

Main functions

Single width 32-bit PMC module, compliant with IEEE P1386.1 standard.
Equipped with a hot swappable PC card slot, supporting 16 bit PC Cards and 32-bit CardBus cards.
Built in PC card controller and power management unit, providing 3.3V, 5V, and 12V voltage for the card, and equipped with hot swappable protection.
The controller register mapping is compatible with the Intel 82365-DF controller specification.
Supports memory and I/O card access for PC cards, including mapping multiple memory windows and I/O windows to the host address space.
The module size is the standard PMC size, approximately 149   mm x 74   mm.
Design modular expansion requirements suitable for embedded and industrial systems.

application
Used in embedded or industrial systems, connecting PCMCIA or CardBus devices through PMC bus to achieve data acquisition, control interface expansion, and other modular functions.

ending
The TPMC871-10 module is reliable and stable, providing flexible I/O expansion capabilities, and is a commonly used interface module choice in industrial and embedded systems.
