Tokyo Electron 1D08-000142-51 Interface PCB Board

Brand:TEL Tokyo Electron
Model:1D08-000142-51
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Tokyo Electron 1D08-000142-51 Interface PCB Board

Product manual:

Tokyo Electron 1D08-000142-51 Interface PCB Board
It is a dedicated signal interface circuit board used in TEL semiconductor equipment,
Mainly responsible for signal connection, relay, and adaptation tasks between different modules within the equipment.
This type of card is often one of the key communication hubs in system control or process modules.

1、 Product Function Overview
Type: Interface PCB board

Function:

Realize signal interaction between the main control system and sub modules;

Perform signal isolation, format conversion, status detection and other processing;

As an I/O interface, it connects with external actuators, sensors, solenoid valves, and drivers.

2、 Main application areas
Semiconductor equipment module connection

Establish a signal bridge between the main control board and the cavity, air circuit, and heating/cooling system;

Support high-speed, low interference data or control signal transmission.

I/O control system

As an input/output interface board, connect various signal sources on the device (such as limit switches, photoelectric sensors, valve drive circuits);

Implement functions such as dry contact signal acquisition, output relay drive, and level conversion.

Communication signal adaptation and distribution

Compatible with signal systems such as RS-232, RS-485, TTL, CAN, etc;

Support isolation or relay between the system bus and peripherals.

Product details picture:

1D08-000142-51
