TRICONEX CM2201 7400206-100 Communication Module

Product manual:

Product Name: Triconex CM2201 Communication Module
Part number: 7400206-100
Product type: Communication Module or Communication Interface Module
System: Triconex Safety Instrumented System (SIS)
Manufacturer: Triconex brand under Schneider Electric

1、 Function Overview
The CM2201 module is the core communication module of the Tricon control system, responsible for communicating with the upper computer system
Communication between third-party control systems and redundant controllers.
Commonly used for critical operations such as system level data synchronization, status monitoring, and data forwarding.

2、 Main technical parameters
Communication interface: serial port, Ethernet (depending on specific configuration)

Bus type: Used for Tricon rack communication slots

Communication protocol support: Supports Modbus, OPC, TCP/IP, UDP, Triconex peer-to-peer communication, etc

Applicable configuration: support communication synchronization in TMR (the third mock examination Redundancy) architecture

Working voltage: Powered by the main system, no external independent power supply is required

Working temperature: 0 ℃ to 60 ℃

Storage temperature: -40 ℃ to 85 ℃

Humidity range: 10% to 90% without condensation

Module hot swappable: Supports

3、 Core Features
High reliability: designed specifically for process safety systems, with redundant communication mechanisms

Real time communication capability: capable of high-speed data exchange with multiple control systems and SCADA systems

Strong system compatibility: compatible with the TRICON v10 and v11 series

Multiple communication methods: Supports multiple independent communication channels to meet complex industrial network topology requirements

Self diagnostic function: equipped with status indication and fault self checking function, easy to maintain

4、 Typical application scenarios
SIS system in petroleum refining equipment

Emergency Shutdown System (ESD) in Chemical Plants

Automated safety protection system for natural gas compression station

Combustion management system and boiler protection system in thermal power plants

Interlocking protection control in high-risk areas

Product details picture:
