TRICONEX DO2401 7400209-030 Digital Output Base
Brand:TRICONEX
Model:DO2401 7400209-030
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
TRICONEX DO2401 7400209-030 Digital Output Base
Product manual:
Model: TRICONEX DO2401
Part number: 7400209-030
Type: Digital Output Baseplate Module
product positioning
DO2401 is a base module used for connecting digital output signals in the Triconex system,
Specially designed to provide hardware connection interfaces for digital output modules such as DO3401.
It transmits the output signal of the control system to the on-site equipment through the wiring terminal,
Such as relays, solenoid valves, contactors, etc.
central role
Provide physical installation interface and on-site wiring terminals for DO3401 digital output module
Connect the module to external loads such as solenoid valves, relays, etc
Provide electrical isolation and fault protection for output channels
Helps achieve seamless integration when maintaining and replacing output modules
Technical Parameter
Adaptation module: Triconex DO3401 digital output module
Number of channels: 32 digital output channels (each channel is independent)
Output voltage: 24 VDC (external power supply)
Load type: Suitable for inductive or resistive loads
Installation method: DIN rail or rack installation
Wiring method: Screw crimping terminal (independent wiring for each channel)
Isolation design: The output channel is electrically isolated from the system bus to enhance anti-interference performance
Protection function: equipped with overcurrent protection, short circuit protection, ground fault protection, etc
Module Features
High reliability: compatible with Tricon triple redundant control system, supporting high availability requirements.
Simple structure: modular design, easy to install and maintain.
Status display: Some versions support LED indicator lights to display channel output status (requires coordination with upper level modules)
Hot swappable support: Supports online module replacement without interrupting system operation.
Strong anti-interference ability: Electrical isolation protection, suitable for industrial sites with complex electromagnetic environments.
Product details picture:
