UniOP eTOP05EB-DF50 Operation Panel

Brand:Uniop
Model: eTOP05EB-DF50
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

UniOP eTOP05EB-DF50 Operation Panel

Product manual:

UniOP eTOP05EB-DF50 is an industrial grade human-machine interface (HMI) control panel launched by EXOR International,
Specially designed for small and medium-sized automation equipment, it has a compact structure, good human-computer interaction performance, and extensive communication compatibility.

The following is a detailed introduction without patterns:

1、 Product Name
UniOP eTOP05EB-DF50 Operation Panel

2、 Product Overview
ETOP05EB-DF50 is a 5.7-inch color resistive touch screen HMI,
Equipped with industrial protection level, supporting multiple communication interfaces and protocols, suitable for embedded control terminals
OEM automation equipment, factory local monitoring systems, and other applications.

3、 Main technical parameters (typical)
Project parameter description
Display screen size 5.7-inch TFT color LCD
Resolution 320 × 240 pixels (QVGA)
Display color 65536 colors (16 bit)
Touch method: resistive single point touch
Backlight type: LED backlight, adjustable brightness
High performance embedded ARM series processors
Memory configuration: Flash ≥ 64MB, RAM ≥ 32MB
Communication interfaces RS232, RS485, USB Host
Power input 24V DC (allowable range 18-30V DC)
Installation method: panel embedded installation, fixed with screws
Protection level: front panel IP65, rear panel IP20 (under standard installation conditions)
Working temperature range: 0 ℃ to+50 ℃
Programming software supports UniOP Designer/JMobile Studio

4、 Main functional features
The graphical interface supports elements such as buttons, switches, icons, trend charts, alarm windows, etc

Built in alarm recording, recipe management, event history and other functions

Multi language support, suitable for international project sites

Supports multiple industrial protocols such as Modbus RTU, Modbus TCP, Siemens S7, Mitsubishi, etc

Support program download and remote debugging through serial port or USB
