Uniop eTOP060050 Control Panel

Brand:Uniop
Model:eTOP060050
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Uniop eTOP060050 Control Panel

Product manual:

UniOP eTOP060050 is one of the UniOP series human-machine interface (HMI) products launched by EXOR company,
Belonging to the economical color graphic touch screen operation panel, it is widely used for local control and monitoring in industrial automation systems.
The following is a detailed description of the model, excluding patterns:

1、 Product Name
UniOP eTOP060050 Control Panel

2、 Product positioning and purpose
ETOP060050 is an economical and compact HMI control panel,
Suitable for local operating interfaces of small and medium-sized automation equipment, OEM embedded systems, and industrial sites.
Support basic functions such as graphic display, parameter setting, alarm recording, and communication monitoring.

3、 Main technical parameters (typical values)
Project parameter description
Screen type: TFT LCD color display screen
Screen size 5.7 inches
Resolution 320 × 240 pixels (QVGA)
Display color 65536 colors
Touch Method: Resistive Touch Screen
Backlight LED backlight, adjustable brightness
Processor ARM9 or Cortex-A series, depending on batch model
Memory configuration: Flash+RAM (typically 128MB Flash/64MB RAM)
Communication interface RS232/RS485 serial port, USB Host, Ethernet (depending on model)
Input voltage 24V DC (typical 18-30V DC)
Protection level front panel IP65 (panel installation)
Operating temperature: 0 ℃ to+50 ℃
Software supports EXOR Designer or JMobile Studio
