UniOP eTOP06C-CE50 Touch Screen Panel

Brand:Uniop
Model:eTOP06C-CE50
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

UniOP eTOP06C-CE50 Touch Screen Panel

Product manual:

1、 Product Name
UniOP eTOP06C-CE50 Touch Screen Panel

2、 Product Overview
The eTOP06C-CE50 features a 5.7-inch TFT color LCD display screen,
Equipped with a resistive touch screen, rich communication interfaces, and industrial grade structural design.
This model is suitable for on-site applications such as mechanical control, process monitoring, OEM embedded systems, etc,
Supports multiple industrial communication protocols and provides real-time monitoring and operation capabilities through a graphical interface.

3、 Main technical parameters (typical configuration)
Project parameter description
Display screen size 5.7-inch TFT color LCD display screen
Resolution 320 × 240 pixels (QVGA)
Display color 65536 colors (16 bit true color)
Touch Method: Resistive Single Point Touch
Backlight type LED backlight, brightness adjustment function
Embedded ARM or PowerPC processor (depending on specific batch/version)
Memory capacity Flash ≥ 64MB, RAM ≥ 32MB
Communication interfaces RS232, RS485, USB Host, Ethernet (10/100 Mbps)
Power input 24V DC (allowable range 18-30V DC)
Protection level: IP65 front panel (embedded installation)
Working temperature: 0 ℃~+50 ℃
The software platform supports EXOR UniOP Designer/JMobile Studio

4、 Main functional features
Support interface elements such as graphical display, dynamic icons, animations, trend curves, alarm windows, etc

Supports various industrial communication protocols such as Modbus RTU/TCP, Siemens S7, Mitsubishi, Omron, Allen Bradley, etc

Built in alarm management, event recording, recipe management and other functions

Multi language support, allowing for quick switching of user interface languages

Support remote download, update, and debugging (via serial port or Ethernet)

Provide USB peripheral support for program updates or data export
