Uniop eTOP507M touch screen

Brand:Uniop
Model:eTOP507M
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Uniop eTOP507M touch screen

Product manual:

The UniOP eTOP507M is a medium-sized industrial grade human-machine interface (HMI) touch screen device in the EXOR International UniOP series,
Design visual operations and data interaction for automated control systems.

The following is a detailed introduction about the eTOP507M without patterns:

1、 Product Name
UniOP eTOP507M touch screen

2、 Product Overview
The eTOP507M is equipped with a 7-inch color TFT LCD display, combined with resistive touch technology and powerful communication capabilities,
Suitable for scenarios such as factory automation, OEM equipment integration, energy and building control, etc,
Meet the human-computer interaction requirements of moderate complexity.

3、 Main technical parameters (typical)
Project parameter description
Display screen size 7-inch TFT LCD color display screen
Resolution 800 × 480 pixels (WVGA)
Display color 65536 colors (16 bit color depth)
Touch method: resistive single point touch
Backlight high brightness LED backlight
ARM Cortex-A series embedded processors
Storage capacity: Flash 128MB or higher, RAM 64MB or higher
Communication interfaces RS232, RS485, USB Host, Ethernet (10/100 Mbps)
Power input 24V DC (allowable range 18-30V DC)
Protection level (front panel) IP65 (embedded installation)
Working temperature range: 0 ℃~+50 ℃
Software supports JMobile Studio (compatible with UniOP project conversion)
