UniOP MKDG-05-0045 Operating Interface Module

Brand:Uniop
Model:MKDG-05-0045
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

UniOP MKDG-05-0045 Operating Interface Module

Product manual:

Introduction to UniOP MKDG-05-0045 Operation Interface Module

1、 Product Overview
UniOP MKDG-05-0045 is a human-machine interface (HMI) module with graphical display and function keys launched by Exor,
Suitable for industrial automation control systems, with good operability and compatibility.
This module belongs to a non touch panel, mainly operated through buttons, suitable for complex industrial environments.

2、 Main technical parameters

Display screen: 240 × 64 pixel monochrome LCD display screen

Operation mode: No touch function, using 20 function keys with replaceable labels

Indicator lights: 25 user controllable LEDs, 5 system status LEDs

Communication interface: Built in RS-232, RS-485, RS-422, 20mA current loop,
Support pluggable communication expansion modules (such as CANopen, DeviceNet, Profibus, Ethernet, etc.)

Programming software: compatible with UniOP Designer software,
Support functions such as graphic configuration, macro commands, alarm management, recipe data, history, user permission management, etc

User memory: standard 512KB, expandable up to 1MB

Real time clock: built-in, supports event recording and timestamp

Power input: 18-30V DC, power consumption approximately 400mA @ 24V

Installation method: panel embedded installation

Weight: Approximately 1.8 kilograms

3、 Typical application areas

Industrial automation production line
Used for human-machine interface operation of packaging, printing, cutting, assembly and other equipment,
Set operating parameters, monitor status, and view alarms.

Mechanical equipment control
Applied to industrial machinery such as injection molding machines, punching machines, winding machines, etc,
Provide intuitive button based interaction to adapt to complex on-site environments.

Building and Energy Management System
As an operation panel integrated into air conditioning control systems, power monitoring systems, water treatment equipment, etc,
Used to set control parameters and view operational information.

Formula and Batch Control System
Manage production parameter formulas, switch between different job programs, and achieve flexible batch switching of products.
