VIBRO-METER 200-566-000-113 Communication Board

Brand:VIBRO-METER
Model:200-566-000-113
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

VIBRO-METER 200-566-000-113 Communication Board

Product manual:

1、 Basic Information
Product model: 200-566-000-113

Product Name: Communication Interface Board

Manufacturer: VIBRO-METER (now a brand under Meggitt)

Equipment category: Interface module for status monitoring system

Typical application: Data communication relay or acquisition interface module in industrial rotating machinery status monitoring system

2、 Function Overview
VIBRO-METER 200-566-000-113 is a communication interface board designed specifically for mechanical vibration monitoring systems, primarily serving as a signal transmission bridge between the monitoring system and upper level control systems such as DCS, PLC, SCADA. It can convert analog/digital signals from sensor modules (such as speed, acceleration, displacement, etc.) or front-end acquisition units into standard communication protocols for transmission.

3、 Technical features
Project parameter description
The communication function provides data communication between the upper system (such as the analysis host or SCADA system)
Interface types may support RS-232/RS-422/RS-485/Modbus/CAN (depending on specific configuration)
The installation method is usually installed inside a 19 inch rack or dedicated chassis
Adaptation system Vibro Meter VM600, VM600Mk2, COMPASS and other status monitoring platforms
Compatible modules can be linked with core modules such as MPC4, IOC4T, CPUM Mk2, etc
The working power supply is usually 24V DC (depending on the system power supply design)
Isolation protection communication interface with electrical isolation design to prevent interference within the system
Industrial grade temperature resistance and anti-interference are suitable for complex electromagnetic environments such as unit control rooms and turbine power generation equipment monitoring rooms

4、 Typical application areas
Gas turbine/steam turbine condition monitoring

Vibration diagnosis system for compressors and pumps

State assessment of rotating machinery in the power, petrochemical, and aviation industries

Communication Expansion for the VIBRO-METER VM600 Series System

Data collection and remote communication relay module
