Vibro Meter IOCN 200-566-101-013 Communication Board

Brand:Vibro-Meter
Model: IOCN 200-566-101-013
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Vibro Meter Communication Board

Product manual:

1、 Product Overview
Vibro Meter IOCN 200-566-101-013 is a key communication module in the Vibro Meter VM600 series monitoring and protection system.
It is responsible for the internal modules of the system as well as external systems such as DCS, PLC, SCADA
The communication bridge between them supports high reliability industrial data transmission.

2、 Product Technical Parameters
Project parameter description
Product model IOCN 200-566-101-013
Product Type: Communication Interface Board (I/O Communication Node)
Communication support with CPUM module and external system bus communication
Insert the installation position into the designated slot in the VM600 rack
Communication protocols typically support Modbus, TCP/IP, RS-485 (depending on configuration)
The power requirement is to be supplied through the main frame (usually 24 V DC)
Working temperature range -20 ° C to+65 ° C
The status indicator light provides LED indications for communication status, faults, operation, etc
Communication ports typically include RJ45, SUB-D, terminal blocks, etc. (depending on configuration)
The maximum data transmission rate supports industrial standard communication rates (such as 9600-115200 bps or 10/100 Mbps)

3、 Main functions
Communication bridging within the system: data exchange with CPUM and I/O modules;

External communication interface: supports connection with upper level systems (such as DCS, PLC) and provides critical status data;

Configuration and diagnosis: Set address, baud rate, and protocol parameters through dedicated configuration software;

Status monitoring: Quickly diagnose communication abnormalities or module failures through LED status lights;

Redundancy support (partial systems): configurable primary/backup communication paths to enhance system reliability.
