Vibro Meter MPC4 200-510-111-034 Mechanical Protection Card

Brand:Vibro-Meter
Model:MPC4 200-510-111-034
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Vibro Meter MPC4 200-510-111-034 Mechanical Protection Card

Product manual:

1、 Product Overview
Vibro Meter MPC4 200-510-111-034 is a high-performance module specifically designed for monitoring and protecting the status of rotating machinery (such as turbines, compressors, fans, etc.) in the VM600 series.
It can receive multiple sensor input signals, provide real-time data processing and alarm functions, and is one of the key components for the safe operation of the unit.

2、 Technical parameters
Project parameter description
Product model MPC4 200-510-111-034
Module type 4-channel mechanical protection card
Number of monitoring channels: 4 independent channels (each channel can be independently configured)
Support signal types such as IEPE accelerometer, velocity sensor, eddy current probe, displacement sensor, etc
Installation method plug-in, suitable for VM600 architecture
The alarm function supports setting two levels of limit values: Alert and Danger
Output type: Relay contact output, analog signal output (4-20 mA)
The power supply is provided by the system main frame (24 V DC)
Working temperature range -20 ° C~+65 ° C
Electrical isolation between channels and output interfaces
Standard certification meets API 670 requirements (depending on system configuration)

3、 Core functions
✅ 4-channel independent monitoring: Each channel can independently receive signals from different types of sensors and set independent alarm thresholds;

Real time data processing: Built in digital signal processor (DSP), supporting algorithms such as trend, peak, envelope, etc;

✅ Dual alarm output: configurable Alert/Ranger alarm logic and drives external relays;

4-20mA output interface: transmit key vibration parameters to control systems such as DCS and PLC;

✅ Status indication: The panel LED indicates the operating status, alarms, and faults of each channel;

✅ Hot swappable support: easy to maintain and replace online, without affecting the overall system operation (according to system configuration).
