WOODWARD 5503-282 Controller Module

Product manual:

The WOODWARD 5503-282 controller module is designed by Woodward for large engines
A high-performance controller module provided by industrial power equipment such as gas turbines or generator sets,
Usually used to achieve precise speed control, load sharing, synchronization, and remote communication functions.

1、 Basic Product Information
Model: 5503-282

Product type: Controller module (may be an extension or specialized model of Woodward 723, 2301D, or MicroNet series)

Application objects: Gas/diesel engines, turbines, generator sets, compressor control systems

2、 Core functional features
Function Description
Engine speed control provides precise PID closed-loop speed regulation, suitable for generator grid connection and islanding operation
Load distribution and synchronization support parallel operation, load distribution (kW), reactive power distribution (kVAr) and other functions
Strong communication capability supporting industrial protocols such as Modbus, CANopen, RS-485, Ethernet, etc. (depending on version)
Remote monitoring and configuration can be achieved through Woodward's tool software (such as Toolkit, Monitor) for remote configuration and real-time monitoring
High reliability and safety industrial grade design, suitable for operating in harsh environments, supporting redundancy and self diagnostic functions
Flexible I/O expansion provides multiple analog/digital input/output channels, making it easy to integrate with sensors and actuators

3、 Typical technical parameters (reference)
Project parameters
Power input 18~32 VDC (usually 24V)
Analog input 0-5 V, 0-10 V, 4-20 mA (depending on module configuration)
Analog output 4-20 mA or PWM (for driving actuators)
Digital input switch input, multi-channel
Digital output relay or open collector electrode output
Communication interface RS-232/RS-485/CAN/Ethernet
Working temperature range -40 ° C to+70 ° C (industrial grade)
The protection level is usually IP20 (installed inside the control cabinet)
