WOODWARD 8440-2050 Generator Set Controller

Details

WOODWARD 8440-2050 Generator Set Controller

Product manual:

The WOODWARD 8440-2050 generator set controller is a high-performance controller launched by Woodward Corporation,
Belonging to the easyYgen-3000XT series, specifically designed for grid connection and synchronization of multiple generator units
Design complex applications such as load distribution, suitable for generator systems driven by various engines such as diesel engines and gas engines.

1、 Product positioning
Woodward 8440-2050 is a multifunctional generator controller with integrated synchronization
This model is usually a variant of the easyYgen-3500XT-P1 or easyYgen-3500XT-P2 series.

2、 Main functions
Synchronization and parallel control: supports automatic synchronization of generators with the power grid or other generator sets;

Load distribution: Supports parallel operation of up to 32 units, with load sharing function;

Circuit breaker control: Built in CB1 (generator side) and CB2 (grid side) circuit breaker control logic;

Automatic start stop and engine management: integrated engine start stop, acceleration, and deceleration logic;

Protection function: It has electrical protection such as overvoltage, undervoltage, overclocking, underfrequency, overcurrent, and power feedback;

Remote communication and monitoring: Supports Modbus TCP/RTU, CANopen, SNMP, RS-485, Ethernet, etc;

Display and human-machine interface: integrated LCD display screen and buttons, capable of local configuration and monitoring of operating status;

Data recording and alarm function: It can record operational data and historical alarm events for easy maintenance and diagnosis.

3、 Technical parameters (brief)
Power input: 8 to 40 VDC

AC voltage measurement: 3-phase 277/480 VAC (L-N/L-L)

Analog input: 8 channels (voltage/current type)

Analog output: 4 channels (0-20 mA)
