YNT511D bus repeater rack

Model: YNT511D
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

YNT511D bus repeater rack

Product manual:

YNT511D bus repeater rack
YNT511D is an S3 bus repeater rack designed by Yokogawa specifically for the CENTUM CS/VP series DCS. It is used to expand the transmission distance of the S3 bus, increase node capacity, and improve system communication reliability.
Core features (15 points)
Specially designed for the S3 bus of the Yokogawa CENTUM CS/VP DCS system, factory matched.
Rack mounted structure, providing standardized installation platform, compatible with Yokogawa S3 bus module.
Supports multi slot expansion and can install multiple bus repeater modules for flexible expansion.
Built in power adapter and signal conditioning provide stable power supply and signal environment for the relay module.
Supports 220-240VAC wide voltage power supply (suffix - V42 version), compatible with industrial power grids.
Industrial grade metal frame, structurally stable, resistant to vibration and impact, suitable for harsh environments.
Effectively extending the transmission distance of S3 bus and breaking through the length limit of single segment bus.
Signal regeneration and shaping, reducing attenuation and distortion in long-distance transmission, and improving communication quality.
Modular plug-in design, supporting online module replacement without affecting system operation.
Built in status indicator light, real-time monitoring of power, communication, and fault status.
Compliant with industrial electromagnetic compatibility (EMC) standards, with strong anti-interference ability.
Wide temperature operation, suitable for industrial environments ranging from -20 ℃ to+60 ℃.
Weighing approximately 6.25kg, it is installed in a standard cabinet and easy to deploy.
Compatible with Yokogawa S3 bus modules such as AIP171, AIP578, PW502, etc.
Typical Applications
Expansion and Long Distance Communication of S3 Bus in Yokogawa CENTUM CS/VP DCS System
Bus interconnection of multi area control stations and I/O stations in large factories
Distributed control systems for process industries such as power plants, chemicals, and metallurgy
Bus expansion and reliability upgrade of old DCS system
Multi node, long-distance industrial fieldbus network construction
