IEPAS02 power module

Model:IEPAS02
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

IEPAS02 power module

Product manual:

IEPAS02 is an AC system power module of ABB Bailey Infi90/Symphony Harmony series, providing core stable power supply for DCS systems.
Positioning: Infi90/Net90 system main AC power supply unit, providing power to the controller, I/O, and system units.
Input specifications: 120/240VAC adaptive, 47-63Hz, input current 3.0/1.7A.
Output: Multiple isolated DC (+5V, ± 15V, 24V) to meet the power supply requirements of the system and on-site equipment.
Capacity: Rated power of 250VA, capable of supplying power to medium and large DCS cabinets.
Isolation: Input and output electrical isolation, strong anti-interference, enhances system safety.
Protection: Integrated multiple protections for overvoltage, overcurrent, short circuit, and over temperature, automatically cutting off in case of abnormalities.
Efficiency: ≥ 90%, low loss, low heat generation, suitable for 7 × 24-hour operation.
Structure: Standard Infi90 6U single slot, compatible with Bailey rack, easy to install.
Status: Equipped with LED indicator light, visually displaying normal/fault/alarm.
Redundancy: Supports N+1 redundancy and works in conjunction with IEPAF01 to build high availability power supply.
Compatibility: Seamless integration with Infi90 and Symphony Harmony systems.
Hot swappable: supports online plugging and unplugging, with non-stop maintenance.
Environment: Operating temperature range of 0-55 ℃, suitable for harsh environments such as power plants, petrochemicals, metallurgy, etc.
Upgrade: Upgraded to IEPAS01, with comprehensive improvements in power density, stability, and protection.
Application: DCS core power supply for large-scale process automation in power, chemical, oil and gas, papermaking, and other industries.
IEPAS02, with its high reliability, strong isolation, and redundancy capabilities, has become the core guarantee module for AC power supply in Infi90 systems.
