NAMM02 Analysis and Simulation Module

Model:NAMM02
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

NAMM02 Analysis and Simulation Module

Product manual:

NAMM02 Analysis and Simulation Module (Analog Master Module)
NAMM02 is a dedicated analog master module for ABB Bailey Net 90/Symphony system. As the core hub of the analog I/O subsystem, it manages and coordinates the data acquisition and control output of analog input/output slave modules.
Positioned as the main module for analog signals in the Net 90 system, responsible for managing analog input/output slave modules (AIOM/AOOM)
Single slot standard rack installation, compatible with Net 90 I/O cabinet layout
Up to 16 analog input/output slave modules can be connected to expand the analog channel capacity
To provide backplane power supply and bidirectional communication from the module, and achieve interaction between the controller and on-site analog signals
Support the integration of various industrial analog signal types such as voltage and current
Built in diagnostic function to monitor module status for easy troubleshooting
Support redundant configuration to enhance system reliability and availability
Powered by 24VDC and designed with low power consumption, suitable for long-term continuous operation
The size is about 178 × 51 × 76mm, the weight is about 0.41-0.86kg, and the structure is compact
The panel is equipped with status LED indicator lights, which intuitively display the operation and fault status
Compatible with Net 90/NFI 90 native protocols, seamlessly integrated with system controllers
Support system expansion, which can meet large-scale analog monitoring needs by adding modules
Industrial grade design, suitable for industrial environments with 0-60 ℃ and 5% -95% no condensation
Widely used for analog data acquisition and control in industries such as power, petrochemicals, metallurgy, and chemical engineering
As an upgraded version of NAMM01, it has better channel capacity and performance, making it suitable for large-scale automation scenarios
NAMM02 serves as the core master station for analog systems
