IMCPM02 Communication Port Module

Model:IMCPM02
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

IMCPM02 Communication Port Module

Product manual:

IMCPM02 Communication Port Module
IMCPM02 is a dedicated communication port module for ABB Bailey INFI 90/Net 90/Symphony systems, providing an RS-232 serial communication interface for data exchange, configuration, and debugging between the system, engineering stations, and PCU controllers.
Standard RS-232 serial interface, supporting up to 115.2kbps baud rate, suitable for communication between PC and control system.
Can be paired with CTT02 tool to achieve parameter tuning, configuration, and online debugging of a single PCU.
Industrial grade wide temperature operation (-20 ℃~+60 ℃), suitable for harsh industrial sites.
Modular compact design, standard rack installation, dimensions approximately 17.8cm x 5.1cm x 2.5cm, weight 0.4kg.
Built in electrical isolation, strong resistance to electromagnetic interference, ensuring stable and reliable communication.
Low power design (<5W), passive heat dissipation, fanless, long-term stable operation.
Seamless compatibility with INFI 90/Net 90 system bus, easy integration.
Support communication status monitoring and online diagnosis for easy troubleshooting and maintenance.
Power supply+5VDC, compatible with the standard power architecture of the system.
Suitable for system configuration, parameter upload and download, controller debugging, and data monitoring scenarios.
IMCPM02, with its stable serial communication, convenient debugging, and high reliability, has become a key module for engineering configuration and communication interaction in the INFI 90 system, ensuring efficient debugging and stable operation of the system.
