IMDSI12 Digital Input Module

Model:IMDSI12
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

IMDSI12 Digital Input Module

Product manual:

IMDSI12 Digital Input Module
IMDSI12 is a universal digital input module for ABB Bailey INFI 90/Symphony system, used to collect discrete signals such as on-site dry contacts, switches, sensors, etc., and provide status monitoring and logic judgment inputs for the system.
16 independent digital input channels, supporting dry contacts and level signals, compatible with 24/48/125VDC and 120VAC multi voltage specifications.
Channel and bus are optically isolated, with an isolation voltage of 500VAC, strong resistance to electromagnetic interference, and suitable for complex industrial environments.
Built in 17ms fixed debounce filter to suppress mechanical switch jitter, stable signal acquisition, and low false triggering rate.
Support jumper configuration of working voltage and AC/DC mode, flexibly adapting to different on-site signals.
Industrial grade wide temperature range: -20 ℃~+60 ℃, resistant to humidity and dust, and capable of long-term stable operation.
Power supply * *+5VDC * *, power consumption of about 5W, low power consumption, passive heat dissipation, high reliability.
Detachable terminal block wiring, supporting pre wiring, high installation and maintenance efficiency.
Modular compact design, standard rack installation, size approximately 17.8 × 5.1 × 33cm, weight 0.2kg.
Compatible with INFI 90/Net 90/Symphony bus and can directly replace IMDSI02 (jumper matching).
Support online diagnosis and status feedback of the system, and quickly locate faults.
Suitable for process control scenarios such as electricity, petrochemicals, metallurgy, power generation and distribution.
IMDSI12, with its multi-channel, high isolation, strong anti-interference, and flexible configuration, has become the core module for digital data acquisition in the INFI 90 system, ensuring stable and reliable access of on-site signals to the control system.
