IMDSM04 Symphony Pulse Input Module

Model:IMDSM04
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

IMDSM04 Symphony Pulse Input Module

Product manual:

IMDSM04 Symphony Pulse Input Module
IMDSM04 is a specialized pulse input module for ABB Bailey INFI 90/Symphony systems, used for high-precision acquisition of pulse signals from encoders, flow meters, speed sensors, etc., to achieve accurate measurement of process parameters such as speed, flow rate, displacement, and counting.
8 independent isolated pulse input channels, supporting 5-24V wide pulse signals, compatible with TTL/HTL/NAMUR standard sensors and orthogonal encoders (A/B/Z phase).
The maximum counting frequency of a single channel is 1MHz, equipped with a 32-bit hardware counter, with a pulse width recognition accuracy of less than 100ns and excellent measurement accuracy.
Channel and backplane optoelectronic isolation ≥ 2500VAC, strong anti electromagnetic interference, eliminates signal crosstalk, suitable for complex industrial sites.
Supports rising edge/falling edge/double-sided edge counting, frequency/cycle measurement, cumulative counting, and speed calculation, with flexible functions.
Built in programmable debounce filter to suppress mechanical switch and sensor jitter, stable signal acquisition, and low false triggering rate.
Industrial grade wide temperature range: -25 ℃~+60 ℃, relative humidity 5% -95% (non condensing), suitable for harsh working conditions.
Power supply * *+5VDC (system backplane)+24VDC (on-site) * *, power consumption of about 3W, low power consumption, passive heat dissipation.
Detachable terminal block wiring, supporting pre wiring, easy installation and maintenance.
Each channel is equipped with status LED, module level fault light synchronization, status visualization, and efficient operation and maintenance.
Support online diagnosis and status feedback, quickly locate faults, and improve system availability.
Seamless compatibility with INFI 90/Net 90/Symphony bus, directly connected to the original DCS architecture without additional adaptation.
IMDSM04, with its high speed, high precision, strong isolation, and flexible configuration, has become the core module for pulse signal acquisition in Symphony systems, ensuring accurate measurement of process parameters and stable system operation.
